Diesel Self-Propelled Platform Trucks
POWERFUL diesel self-propelled modular transporters
Diesel-Powered Self-Propelled Platform Trucks. CAPACITY: 0 – 1000 TONS
Diesel trolleys for EXTREMELY HEAVY-DUTY APPLICATIONS
Combining exceptional flexibility with precise control, our diesel-powered self-propelled modular transporters (SPMT) provide a reliable solution for even the most demanding material handling operations. They are designed to operate efficiently in confined spaces and to transport extremely heavy and bulky loads with maximum safety and stability.
A diesel engine becomes essential when the required performance exceeds the capabilities of battery-powered industrial carts or when operating cycles do not allow sufficient time for battery recharging. Our diesel-powered self-propelled modular transporters ensure consistent performance across all types of surfaces. Thanks to hydraulic axle compensation, uneven or rough ground conditions no longer represent a challenge for material handling operations.
Our motorized industrial transporters can be equipped with either hydraulic motors (hydrostatic transmission) or electric motors powered by an onboard generator. We also offer hybrid self-propelled modular transporters, allowing operators to use the diesel engine outdoors and switch to battery power for indoor operations.
Available on request:
-
- Electronic steering system with multiple configuration options
- Fully automated movement (AGV version)
- Complete customization of all parameters, including size, speed, load capacity, and more
Technical Characteristics
| Capacity | from 1 to over 1,000 metric tons (2,000 to over 2,000,000 lbs) | |
| Dimensions | on request | |
| Steering system | front axle, all axles, ± 90° steering, omnidirectional | |
| Power supply | diesel engine | |
| Speed | on request (from 0.5 mph to 10 mph) | |
| Drive motors | AC electric motors or hydraulic motors | |
| Steering motors | AC electric motors or hydraulic motors | |
| Command | pendant panel, remote controller, footboard, cabin | |
| Type of wheels | solid rubber, polyurethane, pneumatic | |
| Liftable deck | on request (lifting stroke from 2”) | |
| Climbable gradient | on request (from 2% to over 20%) | |
| Operating environment | indoor, outdoor, offshore | |
| Safety systems | laser scanners, sensitive bumpers, ultrasonic sensors | |
| Industry 4.0 ready | on request | |
| Ex conformance | on request (Class 1 and 2, Division 1 and 2, Zone 1 and 2, dust and gas) | |
| Automatic version (AGV) | on request |
